The development is primarily dedicated to residential plotted units, organized within a structured street network. Open green spaces, indicated by tree plantings along roads and a larger area designated as 'OTHER LAND' on the eastern periphery, are integrated into the plan.

• The project benefits from direct access to the significant G.T. Road on its western boundary and Mansarover Road on its southern boundary.
• It establishes connectivity to key regional points, including roads leading 'To GZB.' in the north-west and 'To Dadri' in the south-west.
• The internal road network consists of well-defined streets, specifically 25-foot, 22-foot, and 18-foot wide roads.
• A 45-foot wide road runs along the eastern edge of the development, adjacent to the 'OTHER LAND' area.

• Landscaped green spaces are evident through the depiction of trees along internal roads, enhancing the aesthetic and environmental quality of the development.
• A substantial area labeled 'OTHER LAND' is located on the eastern boundary, serving as a dedicated zone for potential future development or communal open space.
• No other specific amenities such as clubhouses, parks, or sports courts are explicitly labeled or drawn on this master plan.

• The internal road infrastructure includes various widths: 25'-0' WIDE ROAD, 22'-0' WIDE ROAD (multiple segments), and 18'-0' WIDE ROAD.
• Residential plots feature diverse dimensions, with common frontages such as 22'6' and varying depths including 40', 45', 50', and up to 178' for some plots.
• Plot sizes are denoted by units such as 100Y, 125Y, 150Y, 200Y, 210Y, 256Y, 517Y, 112.5Y, 85Y, 172Y, 128Y, 160Y, 60Y, 76Y, 185Y, 101Y, 57Y, 123Y, and 142Y.
• The upper section of the layout plan spans an approximate length of 295 feet.
