Corpora Building Bhandup West, Mumbai

The plan illustrates a primary building structure designated as the 'FIRST FLOOR PLAN,' likely for commercial or office use due to its expansive open layout. The surrounding land is allocated to a peripheral road for vehicular access, extensive parking, and landscaped green zones. These green areas feature planted sections along the boundaries and a central landscaped feature that includes a pond.

• A clear perimeter road facilitates vehicular circulation and leads to designated parking spaces around the building.
• The main access to the building is from the front (south side), directly leading into a foyer.
• The property benefits from external connectivity via LBS Marg, which is approximately 0.1 km away.

• Extensive surface parking is available around the building's perimeter, accommodating numerous vehicles.
• Landscaped areas include a small pond, green lawns, and planted strips along the property boundary, enhancing the aesthetic appeal.
• The building's main entry is through a well-defined foyer, providing direct access to the lifts.
• An outdoor paved area, potentially for seating or a patio, is located along the building's front facade, adjacent to decorative water features.

• The plan indicates two lifts, each with an apparent internal dimension of 2100 x 2100 mm.
• There are two dedicated lift machine rooms: one measuring 4025 x 6100 and another measuring 4025 x 6500.
• A mezzanine floor ('MAZZ FLOOR') is specified with dimensions of 9000 x 3925.
• Locations for Air Handling Unit (AHU) ducts are marked on the plan, signifying HVAC infrastructure.
