The plan primarily designates areas for residential use, represented by multiple blocks (A, B, C, D) often highlighted in yellow or orange. Green areas are incorporated as open spaces or parks, with one notable park explicitly marked in the upper-left quadrant. A specific 'S.R.P. 11.5% COMPONENT' is indicated within the upper-left block, likely pertaining to a Special Residential Project allocation or FSI. The plan showcases a balanced mix of built-up areas and green spaces.

• The project features a well-defined internal road network connecting all residential blocks.
• A clear 'LOCATION OF MAIN ENTRY AND RAMP' is marked in the upper-left section of the plan, indicating the primary access point.
• An internal '15 M WIDE ROAD' is prominent in the lower sections of the plan, facilitating internal circulation.
• The project is externally connected to Swami Vivekanand Road (0.2 km) and Western Express Highway (2.5 km).

• Designated green spaces and a 'PARK' are explicitly marked in the upper-left quadrant, providing recreational areas.
• The layout includes internal courtyards or open areas within some blocks, contributing to resident open space.
• The clearly marked 'LOCATION OF MAIN ENTRY AND RAMP' serves as a specific access amenity.

• An internal '15 M WIDE ROAD' is a key feature of the project's circulation infrastructure.
• The project incorporates an 'S.R.P. 11.5% COMPONENT' within one of its blocks.
• An 'EXISTING 18M WIDE ROAD' is shown along the boundary in the lower-right section of the plan.
• The plan delineates multiple distinct building structures, identified as Block A, Block B, Block C, and Block D.
