This plan specifically illustrates the residential floor layout for Wing A, detailing the arrangement of individual units. The plan does not provide information regarding broader land use, commercial zones, open spaces, or units per acre for the overall project.

• The primary internal circulation is facilitated by a central 6'7' wide passage on each floor of Wing A.
• Each residential unit has direct access from this main passage.
• A staircase is present, indicating vertical connectivity within the building.

• This detailed floor plan focuses on the residential layouts and does not depict any external on-site amenities such as clubhouses, parks, or specific utility placements.

• Wing A features 7 units per floor, with total areas ranging from 394.14 sq.ft. to 627.43 sq.ft.
• The largest unit is Unit 2 at 627.43 sq.ft., and the smallest is Unit 7 at 394.14 sq.ft.
• A central common passage on the floor is 6'7' wide.
• Typical living/dining areas measure 10'0' x 15'7', and bedrooms are commonly 10'0' x 10'0' or 10'4' x 10'6'.

Wing B is designated for residential use, featuring a layout of individual living units, kitchens, bedrooms, and toilets. Common areas include internal passages, lifts, and utility spaces.

• Internal access is provided via a 6'7' wide passage.
• The project is conveniently located near major roads; the New Link Road is 0.4 km away.
• Swami Vivekanand Road is also 0.4 km from the property.
• The Western Express Highway is approximately 2.0 km away.

• The building is equipped with a standard lift, measuring 5'6' x 11'6'.
• A fire lift is also available, with dimensions of 5'9' x 6'6'.
• Essential utilities like electrical ducts and hydrants are integrated into the design.

• The total area of units in Wing B ranges from 393.49 SQ.FT to 517.32 SQ.FT.
• Unit 5 is the largest at 517.32 SQ.FT, while Unit 7 is 393.49 SQ.FT.
• A common passage within the wing measures 6'7' in width.

These plans specifically detail residential units within Wing C, illustrating their internal layouts and the common access passages. There are no explicit labels for commercial zones, open spaces, or any specific percentage allocations within this wing's plan.

• The overall Paradigm Alaya project benefits from its proximity to key roads, with New Link Road and Swami Vivekanand Road both 0.4 km away, and the Western Express Highway located 2.0 km from the site.
• Within Wing C, individual units are accessed via internal passages, some of which are dimensioned at 3'0' x 10'0'.
• A central staircase serves as the primary vertical access within the wing, clearly marked for both upward and downward movement.

• Each residential unit is designed with standard functional spaces, including a kitchen, a living/dining area, bedrooms, and toilet/bath facilities.
• Common building services are supported by integrated utility shafts and ducts.
• The entry point into Wing C for residents includes a designated foyer area.

• Wing C provides a selection of five unit configurations, with total areas ranging from 398.06 sq. ft. to 604.38 sq. ft.
• Individual unit areas are: Unit 1 at 398.06 sq. ft., Unit 2 at 429.05 sq. ft., Unit 3 at 519.01 sq. ft., Unit 4 at 603.91 sq. ft., and Unit 5 at 604.38 sq. ft.
• Common bedroom dimensions observed are approximately 9'0' x 11'3' or 9'0' x 10'0'.
• Living/dining areas are consistently around 9'9' x 18'0' in size.
