Vira Villa Vile Parle East, Mumbai

The plan designates space primarily for an Automatic Pit Puzzle Car Parking System, indicating a high-density parking solution. It also includes areas for essential utilities like underground tanks.

• An entrance (ENT.) and a gate are located on the East side of the property.
• Vertical access within the structure is provided by a Main Lift and a Sub Lift, each with designated lift pits.
• The property is conveniently located 1.0 km from Swami Vivekanand Road.
• It is also 0.5 km from Western Express Highway.

• The primary feature is an Automatic Pit Puzzle Car Parking System, designed for efficient vehicle storage.
• Main and Sub Lifts are integrated for vertical transportation, with dedicated lift pits.
• Underground Tanks (labeled U.G. TANK ABOVE) are strategically placed in both Wing A and Wing B for utility storage.

• The entire parking facility, as depicted, has a significant length of 22.88 meters.
• It accommodates a total of 32 Automatic Pit Puzzle Car Parking slots, with 12 slots designated for Wing A and 20 slots for Wing B.
• Large underground tanks are present, including one in Wing A spanning 9.87 meters in length and another in Wing B spanning 4.10 meters in length.
• The plan is drawn to a scale of 1:100, allowing for precise measurement interpretation.
