Akruthi Springwoods Jigani, Bangalore

The master plan allocates areas for residential plots, several distinct park areas, buffer zones, and civic amenity (CA) areas. Specific land-use percentages or units per acre are not explicitly labeled.

• The internal layout features a structured road network designed to provide access to all plots.
• Road widths within the development vary, indicated as 12.19 M, 10.60 M, 9 M, 8 M, 7.5 M, 14 M, and 6 M wide roads.
• The plan shows a clear hierarchy of internal roads connecting different sections of the development.
• No specific primary access points from external roads are marked on the layout.

• Designated 'BUFFER PARK' areas, including 'BUFFER PARK C-1', are integrated into the layout.
• Multiple 'PARK' areas are present, such as 'PARK C-2' and other green spaces visible throughout the development.
• Several areas are explicitly marked as 'CA' (Civic Amenity) for community facilities.

• The development includes residential plots numbered in various sequences, for example, plots 250 through 269 are part of the 'FIRST PHASE', and another block of plots is numbered from 270 to 313.
• Internal road widths are clearly indicated on the plan, ranging from 6 M to 14 M.
• The master plan includes a clear north arrow for orientation.
