KNS Sumedha Kengeri, Bangalore

The layout primarily features residential plots, interspersed with several green spaces designated as parks.

• The internal network consists of 9.14-meter wide roads, providing clear access throughout the layout.
• A 3-meter wide pathway is also integrated, offering pedestrian access within the community.
• Primary access points include an existing road on the western side and another existing road labeled 'MATRIX MRLA' on the southern side.
• The project benefits from external connectivity to Mysore Road N R Road, approximately 7.0 km away, and the NICE Peripheral Ring Road, which is about 5.0 km away.
• There's also a route indicating connectivity 'TOWARDS MARGONDAKAKILLI' from the southern side.

• The master plan includes five distinct park areas, providing green spaces for residents.
• These park areas have specified sizes: PARK-1 at 11280.41 square meters, PARK-2 at 1186.67 square meters, PARK-3 at 424.45 square meters, PARK-4 at 240.1080 square meters, and another park measuring 353.62 square meters.
• A 3-meter wide pathway is specifically designed for pedestrian movement.

• The layout is bordered by various survey numbers, including SY No 40, SY No 67, and SY No 68.
• The internal roads consistently maintain a width of 9.14 meters.
• Key boundary lengths visible on the plan include 49.00 meters, 165.40 meters, 56.40 meters, 58.00 meters, 104.20 meters, 36.80 meters, 55.20 meters, 35.00 meters, and 103.40 meters.
• Many residential plots within the layout are dimensioned at 9.14 meters by 12.19 meters.
