Honey KS County Bannerghatta, Bangalore

The plan primarily designates land for residential plots, clearly numbered and arranged in blocks. Significant green spaces are integrated throughout the layout, particularly a large park area in the lower-left quadrant. Road networks are allocated to provide access to all plots. Specific unit densities per acre are not specified.

• An extensive internal road network provides access to all individual plots within the development.
• A major access road enters the development from the north-east, running diagonally across the site.
• Another key road defines the western boundary of the residential blocks.
• Road widths are not specified on the plan.

• Multiple green spaces and parks are distributed across the development, including a large central park area in the lower-left.
• Some green areas contain small icons suggesting children's play equipment.
• A designated area in the lower-right quadrant shows a building, likely a clubhouse or community facility, surrounded by green space.

• The residential plots are extensively numbered, with plot numbers ranging from single digits (e.g., 1-22 in one block) to triple digits (e.g., 101-144 in another).
• A clear compass rose is provided in the lower-right indicating the North direction.
• The layout is divided into distinct blocks of plots separated by internal roads.
